【Product advantages】
1. No connection: solar charging and built-in lithium battery power supply;
2. No wiring: no cutting through the wall, no damage to the decoration;
3. No cable: monitoring without cable;
4. Remote view: with network, you can view remotely anytime, anywhere;
5. Human body induction: when sensing a person, take a video immediately;
6. Privacy protection: local storage, no leakage;
7. Two way voice: monitoring recording, real-time intercom;
8. Simple installation: self installation, no need to invite professional construction personnel;
9. double light source night vision full color: white light auxiliary light source, night can also display color picture;
10.Flexible monitoring of the cradle head rotation: the cradle head rotation can be viewed at 320° horizontally and 90°vertically；
11. Support access to Google assistant、Amazon Alexa;
【Product parameters】
|
Produck name
|
SQW-2 Solar WiFi camera
|
SQG-2 Solar 4G camera
|
|
Module
|
Hisilicon Hi3861 low power wi-fi chip
|
Qualcomm High pass chip custom low power module
|
|
Frequency
|
2.4Gwifi
|
Support full spectrum 4G networks in the us, Europe and China
|
|
Distribution network
|
Qr code scanning+Wi-Fi Quick link
|
Qr code scanning
|
|
SIM card
|
Not Supported
|
Nano SIM
|
|
WiFi hotspot
|
Not Supported
|
Not Supported
|
|
Protocol
|
TCP/IP，HTTP，TCP，UDP，SMTP，DHCP，DNS，P2P
|
|
Main Domain Controller
|
T31ZL QFN88
|
|
Image Sensor
|
3MP CMOS sensor SC3336 1/2.8
|
|
Video Streaming
|
2304H*1296V/30fps
|
|
Mobile detection
|
PIR + mobile detection + humanoid detection multiple intelligent detection, effective distance 10 meters
|
|
Night vision mode
|
850nm infrared +White light，App selection
|
|
Night vision distance
|
effective lighting distance of about 10m
|
|
Camera lens
|
3MP High definition camera 3.6MM F=2.8 level FOV 120 degrees
|
|
Battery
|
4*21700 lithium battery, solar rechargeable battery
|
|
Charge
|
8W solar power continuous charging, support USB port about 10 hours full charge
|
|
Wake up/sleep time
|
15s no sleep
|
|
System
|
Lite OS
|
|
Audio
|
Audio codec
|
AAC and G.726
|
|
MIC
|
High sensitivity -38dB
|
|
Video
|
Video code
|
H264/H265
|
|
Features
|
AEESS
|
Support
|
|
ANGLE
|
Horizontal:320°
Vertical:90°
|
|
Key
|
Power/reset key
|
|
Status
|
LED (blue & red)
|
|
Memorizer
|
Support TF Card 4GB-64GB and cloud storage
|
|
Playback
|
Event list and cloud storage playback
|
|
Grade of waterproof
|
IP66
|
|
Full duplex intercom
|
support
|
|
APP
|
ios10.0，android5.0
|
|
Environment
|
Temperature
|
-30℃ ~+60℃
|
|
Humidity
|
≤80%RH
|
