Product model
|
Product model
|
SDB-1
|
|
Scheme
|
Master chip
|
1080p: Ingenic T31ZL/2K: Ingenic T31ZX (Note: The chip will be replaced due to product upgrades without notice)
|
|
Image sensor
|
SC2335/SC233A (Note: Sensor will be replaced due to product upgrades without notice)
|
|
Audio video
|
Pixel
|
200W 1080P resolution
|
|
Video encoder
|
Main stream (HD) : H.265; Substream (SD) : H.264
|
|
Video bitrate
|
Main stream (HD) : 1Mbps; Substream (SD) : 384Kbps
|
|
Video frame rate
|
Main stream (HD) : 1080P@15fps; Substream (SD) : VGA@20fps
|
|
Lens
|
Focal length: 3mm; Aperture: F2.0
|
|
Vision Angle
|
Diagonal 160 °
|
|
Video codec standard
|
H.265/H.264
|
|
Voice intercom
|
Supports bidirectional voice intercom and echo cancellation
|
|
Audio input / output
|
Number 1 Mic / Number 1 Speaker
|
|
Indicator light
|
Green/white dual-color indicator. White is the device status indicator, and green is the charging indicator
|
|
Infrared lamp
|
Six 850nm infrared lamps
|
|
Night vision mode / distance
|
IR-CUT automatically switch / Maximum night vision distance 5m
|
|
Wireless connection
|
2.4 GHz Wi-Fi IEEE 802.11 b/g/n
|
|
Motion detecting
|
Supports PIR body movement detection
|
|
Message function
|
Supports message leaving function
|
|
Ticktok
|
Supports indoor Ticktok
|
RF 433MHz
|
|
Gateway
|
Gateway
|
Supported
|
|
Value-added
function
|
Tuya cloud storage
|
Supports event video
|
|
Amazon Alexa
|
Supported
|
|
Google assistant
|
Supported
|
|
Power supply
|
Power supply
|
DC 5V1A
|
|
Certification
|
Certification
|
CE/FCC/RoHS
|
|
Battery
|
Type
|
Rechargeable battery, non-removable, charge protected
|
|
Capacity
|
5200mAh
|
|
Battery duration
|
4~6 months (10 times a day) (related to the use environment and scene, subject to actual test)
|
|
Environment
|
Temperature
|
-0°C ~ 45°
|
|
Humidity
|
10 ~ 95% without condensation
|
